Lightweight, durable, portable and sanitary - our tri-clamp mixers are utilized across numerous processing industries.
The features of our tri-clamp mixers include:
- Easy attachment to a 3 in. tri-clamp fitting
- Includes FDA lip shaft seal for mixer and liquid ingredient protection
- Constructed with a heavy-duty TEFC electric motor with optional VFD
- Gearbox allows for lower RPMs and higher torque
- Wetted materials made of 316 or 304 grade stainless steel for corrosion and abrasion resistance
- Option to select desired horsepower and shaft length
- Appropriate propeller or hydrofoil impeller matched to the selected horsepower and shaft length.
- Item Number TCM050VGD-24
- Enclosure type IP55
- Gearbox ratio 5:1
- Horsepower 1/2 HP
- Impeller attachment Set screw
- Impeller diameter 11 in.
- Impeller material 316SS
- Impeller type Hydrofoil
- Lead time 3 Business Days
- Motor type TEFC Electric
- Mount Tri-Clamp
- Mount dimension 3 in.
- Number of impellers 1
- Phase 1 Ph.
- Rpm 70-350
- Seal FDA Lip Seal
- Shaft diameter 1 in.
- Shaft length 24 in.
- Shaft material 316SS
- Speed controller Variable Frequency Drive (VFD)
- Voltage 115V
